E50F - Pressure Seal Bonnet Wedge Gate Valve.

E50F Pressure Seal Bonnet Wedge Gate Valve is suitable for high temperature and pressure area applications.

It is in conformity with API 600 standards.

The bonnet connection is designed to provide a positive seal when under pressure.

E50F Features
Available size 50mm(2") to 600mm(24")
Available rating Class 900 - 2500LB
Pressure Seal Bonnet
Flexible Wedge
Outside Screwed & Yoke, Rising Stem
Fire Safe Design
Above Ground & Under Ground (only full confined packing)
Full Bore

Standards
ASME B16.34, according to API 600
Face to Face size ASME B16.10
End Type ASME B16.5 & B16.47 RF/ RTJ (Series A, Optional Series B), B16.25 BW
NACE MR0175, MR0103 (optional)
Test Standard API 598

Operators
Manual Operated (Handwheel or Gearbox)
Motor Operated (Rotork, Auma or others)
Pneumatic Actuators
Hydraulic Actuators

Application
E50F Gate valves can be suitable for LNG, Water, LPG, Renewable and Marine Offshore applications.

E50F - Pressure Seal Bonnet Wedge Gate Valve
After-sales, Service and Spares
Working with our European partners, Advastas are able to supply all client requirements for after-sales service and spares.

For further information contact us by email  , or by using the Contact Form
